>> Specifications of gazebo tent 5×5

 Liri PAG Series:

Type	Span Width	Bay Distance	Eave Height	Ridge Height	Main Profile
PAG	3m/9.8′	3m/9.8′	2.5m	4.3m	65x65x2.5mm(4-channel)
PAG	4m/13′	4m/13′	2.5m	4.8m	65x65x2.5mm(4-channel)
PAG	5m/16.4′	5m/16.4′	2.5m	5.43m	65x65x2.5mm(4-channel)
PAG	6m/19.7′	6m/19.7′	2.5m	5.92m	65x65x2.5mm(4-channel)
PAG	8m/26.2′	8m/26.2′	2.6m	5.36m	122x68x3mm(4-channel)
PAG	10m/32.8′	10m/32.8′	2.6m	6.38m	122x68x3mm(4-channel)
Pagoda tent can be used as a single unit or combined by a rain gutter to make a  larger space or a special structure style. Customized size is available.

• Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
• Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
• Connector: strong hot-dip galvanized steel
• Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
• Wind load: max. 100km/h (can be reinforced)
• Snow load: 75kg/sqm (snow can’t stay if use big degree roof pitch design)
• Easy to be assembled and dismantled, movable.
• No pole inside, 100% available interior space.

  >> Fixing Methods of gazebo tent 5×5

  >> Accessories of gazebo tent 5×5

• Covers: colourful cover, transparent cover, inflatable roof cover
• Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
• Wooden Flooring System: VIP cassette flooring, simple cassette flooring
• Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
• Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
• Fixing Methods: ground anchors, weight plate, expandable bolts
• Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
• Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.

  >> Applications of gazebo tent 5×5

• Widely used for Weddings, Events, Parties, Celebrations,Sports,Tradeshow, Warehouse,etc.

  >> Packaging of gazebo tent 5×5

• aluminum frame packed in membrane film
• hardware packed in solid carton box
• roof and sidewall in professional PVC carry bag

  >> Certificate of gazebo tent 5×5

Tent Roof Type	Span Width	Bay Distance	Eave Height
“A” Shape	3m~60m	3m/5m	2.6m/3m/3.3m/3.88m/4.2m/5m/5.2m
Domelike	3m~40m	3m/5m	2.6m/3m/3.23m/3.88m/3.92m
High Peak	3m~10m	3m/4m/5m/6m/8m/10m	2.5m/2.6m
Curve Shape	15m~40m	5m	3.87m/3.89m
Polygon	10m~60m	5m	4m
Cube Structure	10m~30m	5m	5m



Please note this is a general description.For exact tent type and size please feel free to contact us.





New Product — Liri HST Series: Click the picture for more details!

Liri Tent Technology (Zhuhai) Co., Ltd. was established in 1997. Our company is the first professional manufacturer who introduced European advanced tents technology into our own design. Our main products include Modular Aluminium Alloy Structure Tents, Clear Span Tent Structure and Aluminium Alloy Square Pagoda & Summer Gazebo.



To form an integrated management system,Liri Tent introduced advanced ERP system in 2008 and barcode management system in 2013. Liri Tent is also the pioneer to apply CNC machines that achieved the automatic processing of aluminum.





      LIRI TENT Successful Cases:

• Kinds of New Style Tent for China Open
• Canton Fair Exhibition Hall
• 2011 Universiade Official Tent Supplier
• 2010 Asian Games Exclusive Tent Supplier&Sponsor
• Dior Event in Hong Kong
• China Grand  Rally Sponsor
• Hong Kong Wine and Dine Festival
• ……

Q: Can you print our logos on tent?

• Yes.Customized logos can be print on the tent fabric according to your requirements.

Q: Is that factory price?

• Yes.We assure you all prices are based on factory.

Q: Does your tent be able to install repeatedly?

• Our tents can be assembled and dismantled and repeatedly with small transportation size.The lifespan of aluminium framework can reach 15-20 years,and 5-8 years for PVC fabrics depending on different conditions of usage.

Q: What documents are available?

• A full range documents including structural drawings,packing list,installation manual and relative certificates can be provided.Moreover,customs declaration is provided.We provide one-stop service for you.

Q: Has your tent product been certified?

• Yes.Our tent product has passed the engineering tests and gained the America And Australia structural engineering certificates. Besides, the PVC fabric used for roof covers and sidewalls has passed the fire tests and gained the flame retardant certificates issued by America, Australia, New Zealand, and Britain.

Q: Is your tent strong and stable enough? How about the wind loading?

• Yes.The main frameworks (upright support and roof beam) are manufactured with high impact extruded anodized aluminum (6061/T6) so our tent structure is safe and strong and can resist wind up to 100 km/hr.

Q: How long is the warranty period?

• Guarantee one year. During the warranty period, we shall repair or replace the damaged part accordingly because of any damage due to quality problem.
